Kanro Products

DRAGON

STEAM DEVICE

Efficiency of smoke: 2.800 m/min.
Continuous operation: 60 min.
Fluid consumption: 16 ml / min.
Compact design: weight 7,5 kg

Power of the heating device: 800 Ws

Flexible PVC hose

Aluminium telescopic rod

Simple and safe operation

PRICE:
1600,00 EUR net.

Description

DRAGON – locator developed by KanRo Ltd® is especially useful for professional use for checking pipelines and sewage systems and tanks for leaks and incorrect connections. It is also helpful in searching for cavities, undercuts in embankments and shaft constructions or for checking flat roofs. Another possible application of this device is the simulation of a fire in the case of rescue exercises and training tasks of the fire brigade, as well as examining the distribution of smoke in buildings.

CHARACTERISTIC

Ergonomic and compact design, weight approx. 7,5 kg

Simple and safe operation

Integrated fan with 3-step operation: fog, fog + blower, blower

Infinitely variable speed control of the blower

On / off switch

Ready to work after approx. 2 min.

High efficiency and constant smoke density

The hypertensive safety system

Very low fluid consumption

EQUIPMENT

Flexible PVC hose with a reinforced spiral DN50 with connector C, length 5 m

Aluminium telescopic rod with 3,85 m length

Radio remote with transmitter and receiver (optional)

Supply voltage 230 V / 50-60 Hz, with a 1,5 m long able

Protective cover for telescopic rod, power cable and radio

Original smoke liquid “DRAGON FLUID – HEAVY SMOKE” – 5 liters:

– completely odorless

– completely biodegradable

– harmless to health

– non-flammable and completely free from oils and fats

– ready to use immediately

Specification	Dragon
Continuous operation of the device	about 60 minutes *
The efficiency of smoke	about 85 m3/min. *
Fluid consumption	approx. 0,8 l/h *
The power of the heating device	800 W
Blower power - turbine engine	1400 W
The capacity of the liquid reservoir	0,8 liter
The weight of the dry device	about 7.5 kg
Dimensions	41 x 21 x 18 cm (L x W x H)
Power	230 V / 50-60 Hz (10 A)
